York NTC Temperature Sensor
The YORK International Water Temperature Sensor / Thermistor (Part Number: 025-29964-000) is a heavy-duty NTC temperature tracking probe manufactured in the United States by a Johnson Controls Company. Anchored to a calibration platform of 3000 Ohms @ 25°C, this slide-in immersion element features a highly conductive copper sheath designed to fit standard chiller thermowells, delivering real-time fluid telemetry to prevent evaporator freezing and optimize central cooling loops.
BRAND
YORK International
TYPE
Water Temperature Sensor
PART NO.
025-29964-000
MODEL
3000 Ohms @ 25°C Platform (REV: G)
Full Technical Specifications ▶
| Parameter | Value / Description |
|---|---|
| BRAND | YORK International |
| TYPE | Water Temperature Sensor |
| PART NO. | 025-29964-000 |
| MODEL | 3000 Ohms @ 25°C Platform (REV: G) |
| Voltage Rating | Low-voltage signal circuit input (typically 5V DC control loop via logic card) |
| Application | Measuring waterside loop temperatures (chilled water, condenser water) inside industrial liquid chillers |
| Catalog No. | 025-29964-000 |
| Base Resistance | 3000 Ohms at an ambient tracking reference of 25°C (77°F) |
| Sensor Curve Type | Negative Temperature Coefficient (NTC) Thermistor curve |
| Probe Material | Heavy-duty copper body sheath for high thermal conductivity |
| Mounting Installation | Slide-in immersion element for standard chiller thermal wells (thermowells) |
| Primary Function | Transmits precise analog resistance telemetry mapping fluid shifts back to the microcomputer control center to prevent evaporator freezing |
| Typical Applications | York industrial water-cooled centrifugal chillers, air-cooled screw liquid chillers, and large commercial HVACR central cooling plants |
| Made In | United States (COO: US) |
| REF NO | 132 |
