WIKA Electronic Pressure Transmitter (Flush Diaphragm)
The WIKA S-11 (Part No. 260MFCL / Catalog No. 9073981) is an electronic pressure transmitter with a flush diaphragm, designed for accurate pressure measurement in applications involving viscous, crystallizing, or contaminated media. Its robust stainless-steel construction and hygienic flush process connection make it ideal for industrial, food, pharmaceutical, and process automation applications.
BRAND
WIKA
TYPE
Electronic Pressure Transmitter (Flush Diaphragm)
PART NO.
260MFCL (Catalog Number: 9073981)
MODEL
S-11
Full Technical Specifications ▶
| Parameter | Value / Description |
|---|---|
| BRAND | WIKA |
| TYPE | Electronic Pressure Transmitter (Flush Diaphragm) |
| PART NO. | 260MFCL (Catalog Number: 9073981) |
| MODEL | S-11 |
| Voltage Rating | DC 10 ... 30 V |
| Application | Measuring of viscous, paste-like, adhesive, crystallizing, particle-laden, and contaminated media (e.g., Food & Beverage, Hydraulics, Waste Water) |
| IEC | IP 65 (Ingress Protection rating via its EN 175301-803 L-plug connector) |
| Measuring Range | 0 ... 400 bar (Gauge Pressure) |
| Output Signal | 4 ... 20 mA, 2-wire configuration |
| Design Feature | It features a front-flush diaphragm process connection |
| Material | Wetted parts and body are constructed from robust stainless steel (SS 316L / 1.4435) to resist aggressive media |
| Permissible Medium Temperature | -30 °C to +100 °C (-22 °F to +212 °F) under standard operations |
| Made In | Germany |
| REF NO | 1225 |
