TSURUGA ELECTRIC Relay Meter
TSURUGA ELECTRIC TME-152 Relay Meter is a compact industrial relay meter designed for accurate process monitoring and control. It provides precise measurement with built-in relay outputs for alarm or control functions, making it suitable for use in automation systems, control panels, and industrial process applications.
BRAND
TSURUGA ELECTRIC
TYPE
Relay Meter
PART NO.
TSURUGA ELECTRIC TME-152
MODEL
TME-152
Full Technical Specifications ▶
| Parameter | Value / Description |
|---|---|
| BRAND | TSURUGA ELECTRIC |
| TYPE | Relay Meter |
| PART NO. | TSURUGA ELECTRIC TME-152 |
| MODEL | TME-152 |
| Input Signal | DC 4 to 20 mA |
| Measurement Range | -300 to +300 mm |
| Scale Unit | mm |
| Display Type | Analog Mechanical Pointer Display |
| Meter Class | Class 1.5 |
| Magnet Material | Fe1.6 |
| Accuracy | Class 1.5 |
| Installation Type | Panel Mount |
| Operating Principle | Moving Coil Receiving Meter |
| Output / Indication | Analog Position / Process Value Indication |
| Application | Position indication, valve position monitoring, marine automation systems, industrial process monitoring and control applications |
| Scale Specification | -300 ~ +300 mm |
| Instrument No | UZ603888 |
| Compliance | RoHS Compliant |
| Mounting Orientation | Horizontal Panel Mount |
| Made In | Japan |
| REF NO | 1263 |
