Trafag Pressure Switch P25 / P-900 Pressostat
Trafag 900.2380 (P25 / P-900 Pressostat) Pressure Switch is a rugged mechanical pressure switch designed for dependable pressure monitoring and switching in hydraulic, pneumatic, marine, and industrial systems. It features an adjustable pressure setpoint, high switching accuracy, durable metal housing, and reliable operation in demanding environments with high vibration and mechanical stress.
BRAND
Trafag
TYPE
Pressure Switch
PART NO.
900.2380
MODEL
P25 / P-900 Pressostat
Full Technical Specifications ▶
| Parameter | Value / Description |
|---|---|
| BRAND | Trafag |
| TYPE | Pressure Switch |
| PART NO. | 900.2380 |
| MODEL | P25 / P-900 Pressostat |
| Product Category | Electromechanical Pressure Switch |
| Pressure Range (Bereich) | 2...25 bar |
| Maximum Pressure (Pmax.) | 40 bar |
| Pressure Display | Adjustable mechanical pressure setting indicator (2–25 bar scale) |
| Electrical Rating (AC) | 250 V AC, 10(3) A |
| Electrical Rating (DC) | 24 V DC, 2 A |
| Measuring Principle | Bellows Pressure Element |
| Application | Pressure monitoring and switching for marine hydraulic systems, compressors, pumps, lubrication systems, engine protection, ship automation and industrial machinery. |
| Operating Temperature | Ambient: -25°C to +70°C (Series specification) |
| Mounting Position | Multiple mounting orientations supported |
| Made In | Switzerland |
| REF NO | 363 |
