Trafag AG
The Trafag AG PV16 Series 903.2379.905 is an adjustable electromechanical pressure switch designed for reliable pressure monitoring and control in hydraulic, pneumatic, marine, and industrial systems. It features a rugged IP65 aluminum housing, bellows sensing element, adjustable switching differential, and an SPDT microswitch output for dependable operation in harsh environments.
BRAND
Trafag AG
TYPE
Adjustable Electromechanical Pressure Switch
PART NO.
903.2379.905
MODEL
PV16 Series
Full Technical Specifications ▶
| Parameter | Value / Description |
|---|---|
| BRAND | Trafag AG |
| TYPE | Adjustable Electromechanical Pressure Switch |
| PART NO. | 903.2379.905 |
| MODEL | PV16 Series |
| Pressure Range | 1...16 bar (0.1...1.6 MPa) |
| Maximum Pressure | 24 bar (2.4 MPa) |
| Switching Differential | Adjustable, approximately 1...7.5 bar |
| Housing Protection | IP65, Epoxy-Coated Aluminum Housing |
| Electrical Rating | 250 V AC / 15 (1.25) A, 30 V DC / 15 (1.5) A |
| Sensor Element | Bellows Pressure Element |
| Pressure Display | Integrated Mechanical Pressure Indicator |
| Calibration | Factory Calibrated for Decreasing Pressure |
| Application | Pressure monitoring and switching for hydraulic, pneumatic, compressor, marine, industrial process, and automation systems. |
| Made In | Switzerland |
| REF NO. | 531 |
