Siemens Mechanical Position Switch SIRIUS 3SE5
The Siemens SIRIUS 3SE5 Mechanical Position Switch (P/N: 3SE5122-0CE01) is a heavy-duty industrial limit switch designed to detect the position or movement of machinery and mechanical components. It provides reliable switching for machine control, safety interlocking, and position monitoring, making it suitable for industrial automation, conveyor systems, and marine equipment applications.
BRAND
Siemens
TYPE
Mechanical Position Switch
PART NO.
3SE5122-0CE01
MODEL
SIRIUS 3SE5
Full Technical Specifications ▶
| Parameter | Value / Description |
|---|---|
| BRAND | Siemens |
| TYPE | Mechanical Position Switch |
| PART NO. | 3SE5122-0CE01 |
| MODEL | SIRIUS 3SE5 |
| Actuator Type | Roller Lever, Metal Lever with Plastic Roller (22 mm) |
| Rated Operational Current (AC-15) | 6 A at 240 VAC |
| Rated Impulse Withstand Voltage (Uimp) | 6 kV |
| Operating Frequency | 50/60 Hz |
| Ambient Operating Temperature | -25°C to +85°C |
| Storage Temperature | -40°C to +90°C |
| Application | Position detection, machine safety interlocking, conveyor systems, packaging machinery, machine tools, industrial automation, and limit position monitoring. |
| Made In | Germany |
| REF NO | 1516 |
