Robust Data Comm RDC485IC Serial Converter
The Saginomiya DNS-D606M (Part Number: 0277332) is a Japanese-made, high-reliability Combined Low-Pressure & High-Pressure Dual Controller. It houses both high-side overpressure protection and low-side system automation within a single compact module, featuring standard 230V AC (1A / 12A) electrical contacts and an IP20 dust-safe housing
BRAND
Robust Data Comm
TYPE
Isolated RS-232 to RS-485 Serial Converter
PART NO.
RDC485IC-DV-3P-CD
MODEL
RDC485IC
Full Technical Specifications ▶
| Parameter | Value / Description |
|---|---|
| BRAND | Robust Data Comm |
| TYPE | Isolated RS-232 to RS-485 Serial Converter |
| PART NO. | RDC485IC-DV-3P-CD |
| MODEL | RDC485IC |
| Voltage Rating: | 9 to 36 VDC (1.25 Watt power consumption) |
| Application: | Industrial automation networks, maritime data systems, PLC communication setups, and electrical isolation of long data runs |
| IEC | Complete 3-of-3 port galvanic isolation tested up to 2500V |
| Serial no. | R48502-KG6990 |
| Full 3-Port Isolation Architecture | The "3p" build profile delivers a high-level 3-way isolation setup |
| Flexible RS-485 Node Capabilities | 2-wire half-duplex or 4-wire full-duplex |
| Plug-and-Play Hardware RS-232 Side | DB9 Female connector |
| Plug-and-Play Hardware RS-485 Side | removable 5-way terminal screw block |
| Industrial Status Diagnostics | Power input, Transmit (TX) activity, and Receive (RX) loops |
| Made In | Singapore |
| REF NO | 93 |
