Rexroth Mecman Air Pressure Regulator
The Rexroth Mecman REG.C4i (Part No. 5351400200) is a precision air pressure regulator designed to maintain a stable and adjustable outlet pressure in compressed air systems. It provides accurate pressure control, improves pneumatic system performance, and ensures reliable operation in industrial automation, machinery, and process control applications
BRAND
Rexroth Mecman
TYPE
Air Pressure Regulator
PART NO.
5351400200
MODEL
REG.C4i
Full Technical Specifications ▶
| Parameter | Value / Description |
|---|---|
| BRAND | Rexroth Mecman |
| TYPE | Air Pressure Regulator |
| PART NO. | 5351400200 |
| MODEL | REG.C4i |
| PRODUCT DESIGNATION | REG.C4i Pneumatic Pressure Regulator |
| REGULATOR TYPE | Diaphragm Pressure Regulator |
| MAXIMUM SUPPLY PRESSURE | 12 Bar (174 PSI) |
| SECONDARY PRESSURE RANGE | 0.5 to 10 Bar (7 to 145 PSI) |
| NOMINAL FLOW RATE | Up to 1400 Nl/min (49 SCFM) |
| PORT CONNECTION | Without Flange Configuration |
| PRESSURE GAUGE CONNECTION | G 1/8 ISO 228/1 |
| MEDIUM | Compressed Air |
| BODY MATERIAL | Zinc Die-Cast |
| WEIGHT | Approx. 0.3 kg (0.66 lbs) |
| AMBIENT TEMPERATURE RANGE | +5°C to +50°C (+41°F to +122°F) |
| OPERATING TEMPERATURE WITH DRY AIR | 0°C to +50°C (+32°F to +122°F) |
| MOUNTING | Modular FRL System Mounting |
| APPLICATION | Pneumatic control systems, industrial automation, air preparation units, compressed air distribution systems |
| FEATURES | Self-relieving diaphragm regulator with adjustable outlet pressure |
| MARKING ON UNIT | REG.C4i |
| PRESSURE MARKING ON LABEL | 12 BAR |
| MADE IN | Germany |
| REF NO | 1256 |
