Phoenix Contact QUINT-PS/24DC/24DC/5 DC/DC Converter
Phoenix Contact QUINT-PS/24DC/24DC/5 (2320034) is a compact DIN-rail mounted DC/DC converter that provides a regulated 24 V DC output at 5 A (120 W) from a 24 V DC input. It features galvanic isolation, high efficiency, and Phoenix Contact’s SFB Technology for reliable system protection and industrial power applications
BRAND
Phoenix Contact
TYPE
DC Converter
PART NO.
2320034
MODEL
QUINT-PS/24DC/24DC/5
Full Technical Specifications ▶
| Parameter | Value / Description |
|---|---|
| BRAND | Phoenix Contact |
| TYPE | DC Converter |
| PART NO. | 2320034 |
| MODEL | QUINT-PS/24DC/24DC/5 |
| Voltage Rating | Input: 24V DC (Operational range: 18–32V DC, 7A max) | Output: 24V DC / 5A (Boost: 6.25A; SFB: 30A for 12ms) |
| Application | Industrial automation voltage stabilization, marine propulsion systems, and critical control loop decoupling |
| IEC Standards | Conforms to EN 61000-6-2 (Immunity), EN 61000-6-3 (Emissions), and IEC 61140 Protection Class I |
| Selective Fuse Breaking (SFB) Technology | Supplies up to 6 times the nominal current rating (30A for 12 milliseconds) to rapidly trip standard circuit breaker |
| Power Boost Capacity | continuous static power expansion up to 6.25A |
| Thermal Management Profile | Operates at full load from -25°C to +60°C |
| Front Diagnostics Indicators | Features localized status LEDs including Boost (Yellow power expansion state), DC OK (Green output tracking window), and a specialized indicator for \(U_{IN} < 19.2\text{V}\) indicating low supply network conditions |
| Maritime Industry Certifications | Germanischer Lloyd (GL), Lloyd's Register, American Bureau of Shipping (ABS), and ClassNK |
| Hazardous Location Ratings | Listed under file cULus 31ZN for installation inside North American Class I, Division 2, Groups A, B, C, and D |
| Made In | China |
| REF NO | 475 |
