Phoenix Contact FL SWITCH 2208 Managed Ethernet Switch
Phoenix Contact FL SWITCH 2208 (Order No. 2702327) is a managed industrial Ethernet switch designed for reliable and secure network communication in industrial automation systems. It features advanced network management functions, robust industrial-grade construction, and high-performance data transmission, making it ideal for factory automation, process control, and critical industrial networking applications
BRAND
Phoenix Contact
TYPE
Managed Industrial Ethernet Switch
PART NO.
2702327
MODEL
FL SWITCH 2208
Full Technical Specifications ▶
| Parameter | Value / Description |
|---|---|
| BRAND | Phoenix Contact |
| TYPE | Managed Industrial Ethernet Switch |
| PART NO. | 2702327 |
| MODEL | FL SWITCH 2208 |
| Voltage Rating | Nominal Supply: 24 V DC / 48 V DC Voltage Range: 12 V DC ... 57 V DC (Dual redundant input support via US1/US2) |
| Application | Localized data routing, network segmentation, and communication management for PROFINET (Conformance Class B) and EtherNet/IP automation systems in marine and industrial control environments |
| IEC | Conforms to network security standard IEC 62443-4-1 / IEC 62443-4-2; Degree of protection IP20 |
| Port Configuration | Equipped with 8 RJ45 ports supporting 10/100 Mbps transmission speeds with auto-negotiation and auto-crossing features |
| Current Consumption Parameters | Maximum loop draw spikes up to 1.3 A at minimum voltage parameters, while maintaining a standard quiescent load of 185 mA at a constant 24 V DC supply feed |
| Hazardous Environment Ratings | Certified for Class I, Division 2, Groups A, B, C, and D (Temp Code T4) [Class I, Zone 2, Group IIC T4]; ATEX directive DEMKO 16 ATEX 1709X and IECEx ULD 16.0018X |
| Marine Class Certifications | Formally type-approved by DNV GL for continuous operation on heavy marine bridge |
| Ambient Operating Range | -40°C to +70°C |
| Made In | Germany |
| REF NO | 1511 |
