Pepperl+Fuchs KFD2-EB2 Power Rail Interface Module
Pepperl+Fuchs KFD2-EB2 Power Rail Interface Module (Part No. 43546)is a reliable interface module designed to distribute power and communication across the Pepperl+Fuchs Power Rail system for K-System signal conditioning modules. It ensures secure power transmission, simplified wiring, and dependable system operation, making it ideal for process automation, hazardous-area installations, and industrial control applications.
BRAND
Pepperl+Fuchs
TYPE
Power Rail Interface Module
PART NO.
43546
MODEL
KFD2-EB2
Full Technical Specifications ▶
| Parameter | Value / Description |
|---|---|
| BRAND | Pepperl+Fuchs |
| TYPE | Power Rail Interface Module |
| PART NO. | 43546 |
| MODEL | KFD2-EB2 |
| MANUFACTURER | Pepperl+Fuchs |
| Supply Voltage | 20–30 V DC |
| Output Current | Max. 4 A |
| Fuse Rating | 5 AT / 250 V AC (Replaceable) |
| Recommended Fuse Utilization | 80% Maximum |
| Relay Contact Rating | 30 V AC, 2 A, cos φ ≥ 0.7; 40 V DC, 2 A |
| Status Indication | Status Indication |
| Input Connection | Terminals 11+, 12− and 8+, 9− |
| Connection Type | Screw Terminals |
| Mounting Type | 35 mm DIN Rail Mount (EN 60715:2001) |
| Degree of Protection | IP20 (IEC 60529:2001) |
| Ambient Temperature | -40°C to +70°C (-40°F to +158°F) |
| Weight | Approximately 100 g |
| Application | Power distribution and fault monitoring for Pepperl+Fuchs K-System intrinsic safety interface modules |
| IEC | IEC 60529:2001, EN 60715:2001 |
| Made In | Germany |
| REF NO | 1460 |
