Pepperl+Fuchs Incremental Rotary Encoder
The Pepperl+Fuchs RHI58N-0AAK1R61N-01024 Incremental Rotary Encoder is a high-performance position and speed feedback device designed for demanding industrial automation and motion control applications. It delivers accurate incremental pulse output for precise shaft position and rotational speed measurement, ensuring reliable performance in motors, conveyors, and process control systems.
BRAND
Pepperl+Fuchs
TYPE
Incremental Rotary Encoder
PART NO.
123023
MODEL
RHI58N-0AAK1R61N-01024
Full Technical Specifications ▶
| Parameter | Value / Description |
|---|---|
| BRAND | Pepperl+Fuchs |
| TYPE | Incremental Rotary Encoder |
| PART NO. | 123023 |
| MODEL | RHI58N-0AAK1R61N-01024 |
| MANUFACTURER | Pepperl+Fuchs |
| Application | Rotary position and speed feedback for industrial automation, motion control, servo drives, and marine automation systems |
| IEC | CE Marked, UL Listed (Class 2 Circuit) |
| Shaft Type | Shaft Type |
| Housing Diameter | Ø58 mm |
| Resolution | 1024 Pulses Per Revolution (PPR) |
| Detection Principle | Photoelectric Sampling |
| Output Type | RS-422 Incremental Line Driver |
| Supply Voltage Range | 10…30 V DC |
| Maximum Output Frequency | 200 kHz |
| Maximum Load Current | 20 mA per Channel |
| Electrical Connection | Radial Cable Connection |
| Cable Type | Multi-core Shielded Cable |
| Housing Material | Metal |
| Interface | RS-422 Differential Output |
| Made In | Germany |
| REF NO | 1229 |
