Omron H3YN-4 Miniature Timer Relay i
Omron H3YN-4 Miniature Timer Relay is a compact and reliable timing relay designed for precise time-delay control in industrial automation systems. It offers adjustable timing ranges, stable operation, and easy panel integration, making it ideal for control panels, machinery sequencing, motor control, and process automation applications.
BRAND
Omron
TYPE
Miniature Timer Relay
PART NO.
Miniature Timer Relay H3YN-4
MODEL
H3YN-4
Full Technical Specifications ▶
| Parameter | Value / Description |
|---|---|
| BRAND | Omron |
| TYPE | Miniature Timer Relay |
| PART NO. | Miniature Timer Relay H3YN-4 |
| MODEL | H3YN-4 |
| MANUFACTURER | Omron Corporation |
| Application | Industrial control panels, automation sequencing, motor control, process timing, and relay delay applications |
| Time Range | 0.1 s to 10 min |
| Frequency | 50/60 Hz |
| Contact Configuration | 4PDT (4 changeover contacts) |
| Resistive Contact Rating | 3A at 250V AC / 3A at 30V DC |
| AC-15 Rating | 2A at 250V AC |
| Power Terminals | 13~ / 14~ |
| Time Selection | Front DIP switch configuration |
| DC-13 Rating | 0.5A at 30V DC |
| Made In | China |
| REF NO | 317 |
