Omron E5EZ-C3T Digital Temperature Controller
The Omron E5EZ-C3T is a 1/8 DIN digital temperature controller manufactured by Omron Corporation. Engineered for precision heating/cooling loop process management and machinery temperature control, this unit features a wide power supply rating of 100 to 240 V AC (50/60 Hz).
BRAND
OMRON
TYPE
Temperature Controller
PART NO.
E5EZ-C3T
MODEL
E5EZ Series (E5EZ-C3T)
Full Technical Specifications ▶
| Parameter | Value / Description |
|---|---|
| BRAND | OMRON |
| TYPE | Temperature Controller |
| PART NO. | E5EZ-C3T |
| MODEL | E5EZ Series (E5EZ-C3T) |
| Voltage Rating | 100 to 240 VAC (50/60 Hz), 8.5 VA |
| Application | Precision heating/cooling loop process management and machinery temperature control |
| Primary Control Output | 4 to 20 mA DC / 0 to 20 mA DC |
| Alarm Output Auxiliary Loops | 3 independent alarm relay outputs |
| Supported Sensor Inputs | Multi-input configuration supporting Thermocouple (TC) or Resistance Thermometer (Pt100 RTD) loops |
| Terminal Map Assignments | Terminals 1-2 (Power supply) | Terminals 3-4 (OUT1) | Terminals 5 to 10 (Alarm outputs) |
| Front Panel Ingress Class | IP66 water-resistant and dust-tight front faceplate assembly rating |
| Mounting Architecture | Standard panel flush-mount setup requiring a standard 1/8 DIN chassis cutout cutout layout |
| Made In | China |
| REF NO | 165 |
