Noris FA2H Speed Sensor
The Noris FA2H-3C-90 (FA2H Series / FA2-C Platform) is a German-made, heavy-duty Differential Hall-Effect Speed Pick-Up Sensor designed for commercial marine vessels and heavy machinery. Operating on a 10 VDC to 30 VDC supply, it measures the rotational speed of ferromagnetic toothed wheels, diesel engines, turbochargers, and gearboxes
BRAND
Noris
TYPE
Speed Sensor / Pick-up Sensor
PART NO.
FA2H-3C-90
MODEL
FA2H Series
Full Technical Specifications ▶
| Parameter | Value / Description |
|---|---|
| BRAND | Noris |
| TYPE | Speed Sensor / Pick-up Sensor |
| PART NO. | FA2H-3C-90 |
| MODEL | FA2H Series |
| Voltage Rating | 10 VDC to 30 VDC (Standard loop power supply) |
| Catalog No. | FA2H-3C-90 |
| Application | Measuring speed of ferromagnetic toothed wheels, diesel engines, turbochargers, and gearboxes on commercial marine vessels |
| IEC | IP66/IP68 heavy industrial environmental protection sealing standard |
| Serial no. | B88807 #004 |
| Near-Zero Standstill Detection | < 0.2 Hz up to 20,000 Hz |
| Push-Pull Output Configuration | It is continuously loadable with up to 50 mA Sink and 50 mA Load configurations to direct-drive downstream marine alarm monitoring inputs |
| Pressure-Tight Hermetic Shell | The housing is IP68-certified and factory pressure-tightness tested up to 5 bar to prevent hot lube oil or ambient engine workspace vapors from degrading the electronics |
| Differential Hall-Effect Principle | Employs a non-contact differential Hall-effect sensor chip to scan the rotation of ferromagnetic toothed wheels |
| Made In | Germany |
| REF NO | 96 |
