MEAN WELL NDR-120-24 DIN Rail Power Supply
MEAN WELL NDR-120-24 is a slim DIN rail switching power supply designed to provide a stable 24 V DC output for industrial automation and control systems. Featuring a compact design, high efficiency, and reliable performance, it offers overload, overvoltage, and short-circuit protection, making it ideal for control panels, factory automation, and industrial power distribution applications
BRAND
MEAN WELL
TYPE
Slim DIN Rail Switching Power Supply
PART NO.
Switching Power Supply NDR-120-24
MODEL
NDR-120-24
Full Technical Specifications ▶
| Parameter | Value / Description |
|---|---|
| BRAND | MEAN WELL |
| TYPE | Slim DIN Rail Switching Power Supply |
| PART NO. | Switching Power Supply NDR-120-24 |
| MODEL | NDR-120-24 |
| Voltage Rating | Input: 100-240VAC (2.6A 50/60Hz) | Output: 24VDC / 5A |
| Application | Provides regulated 24V DC power to industrial control systems, automation panels, and marine machinery distribution boards |
| IEC | Conforms to EN 61000-6-2 (Industrial immunity standard) and EN 55032 Class B (EMC emissions control standard) |
| Total Rated Power | 120 Watts continuous output power capacity |
| Output Voltage Adjustment | Features a front-facing "+V ADJ" manual trim trimmer potentiometer to calibrate the voltage |
| Status Indication | Equipped with a green "DC OK" LED indicator to monitor stable operational voltage levels |
| Physical Profile | Slim 40mm metal chassis design |
| Made In | China |
| REF NO | 1507 |
