IFM electronic SR0150 Control Monitor for Flow Sensors
The IFM Electronic SR0150 (VS3000) is a 24 VDC control monitor designed for use with IFM flow sensors to monitor liquid and gas flow in industrial applications. It processes sensor signals and provides reliable switching outputs for flow detection, helping ensure safe operation and protection of pumps, cooling circuits, and process systems
BRAND
IFM electronic
TYPE
Control Monitor for Flow Sensors
PART NO.
SR0150
MODEL
VS3000
Full Technical Specifications ▶
| Parameter | Value / Description |
|---|---|
| BRAND | IFM electronic |
| TYPE | Control Monitor for Flow Sensors |
| PART NO. | SR0150 |
| MODEL | VS3000 |
| Voltage Rating | 24 V DC (+10% / -20% voltage tolerance) |
| Application | Designed for connecting type SF5 flow sensors to perform integrated liquid/gas flow, temperature, and wire-break loop fault monitoring |
| IEC | Electrical Protection Class III; IP20 casing safety standard |
| Output Contact Switching Function | Potential-free relay outputs rated for a maximum contact load of 4 A (250 V AC / 30 V DC) |
| Control Adjustment Layout | Front panel integration featuring fine potentiometer controls for custom sensor switchpoint limits and multi-color LED bar graph tracking |
| Inter-Wiring Connection | Relies on premounted Combicon terminal blocks featuring durable screw clamps for rapid cable termination maintenance |
| Operational Medium Setting | Preconfigured for liquid media on delivery. Can be adjusted for gas monitoring applications by hard-wiring a custom wire bridge across terminals 23 and 24 |
| Made In | Germany |
| REF NO | 1466 |
