Georgian BXNE372002 Intrinsically Safe Power Supply / Safety Barrier Module
The Georgin BXNE372002 is a dual-channel intrinsically safe power supply and galvanic isolation barrier manufactured by Georgin in France. It is specifically engineered to provide safe power transmission to field sensors deployed in ATEX explosive hazardous zones, offering up to 2500 V AC dielectric insulation between safe and hazardous ports. This DIN-rail mounted module features versatile supply options supporting 110/230 VAC or 24/48 VDC, is fully compliant with SIL safety integrity protocols
BRAND
GEORGIN
TYPE
Safe Power Supply
PART NO.
BXNE372002
MODEL
BXNE372002
Full Technical Specifications ▶
| Parameter | Value / Description |
|---|---|
| BRAND | GEORGIN |
| TYPE | Safe Power Supply |
| PART NO. | BXNE372002 |
| MODEL | BXNE372002 |
| Voltage Rating | Supply Options: 110/230 VAC or 24/48 VDC galvanic loop matching |
| Catalog No. | BXNE372002 |
| Application | Provides intrinsically safe power transmission to field sensors deployed in ATEX explosive hazardous zones |
| IEC | EN/IEC 60079-0 / EN/IEC 600079-11 / IEC 61508 |
| Serial no. | 161984 |
| Safety Channel Matrix | Dual-channel independent safety isolation network infrastructure |
| Maximum Safety Voltage | Up to 2500 V AC dielectric insulation rating between safe and hazardous ports |
| Maximum Output Safety Current | Conforms to strict ATEX/IECEx current threshold limitations |
| Manufacturing Vintage | Engineered and built in 2011 |
| Mounting Orientation | 35 mm DIN rails |
| Made In | France |
| REF NO | 150 |
