Emerson Pneumatic Positioner 3660
The Fisher (Emerson) Type 3660 Pneumatic Positioner (Part Number: 51B3944X032) is a standard travel, standard lever pneumatic control module designed for precise valve actuator positioning.Manufactured in China, this positioner operates within an input signal range of 3–15 psi (0.2–1.0 bar) to maintain exact valve position control. It is built for rugged industrial process control environments, offering an extensive operating temperature range from -40°F to +250°F (-40°C to +121°C).
BRAND
Emerson
TYPE
Pneumatic Positioner
PART NO.
51B3944X032
MODEL
3660
Full Technical Specifications ▶
| Parameter | Value / Description |
|---|---|
| BRAND | Emerson |
| TYPE | Pneumatic Positioner |
| PART NO. | 51B3944X032 |
| MODEL | 3660 |
| PRODUCT NAME | Fisher Type 3660 Pneumatic Positioner |
| SERIAL NUMBER | F003458919 |
| INPUT SIGNAL RANGE | 0.2–1.0 bar |
| INPUT SIGNAL | 3–15 psi |
| DESCRIPTION | Positioner Platform for Type 3660, Standard Travel (STD TVL), Standard Lever (STD LEV) |
| AMBIENT TEMPERATURE RANGE | -40°F to +250°F (-40°C to +121°C) |
| FUNCTION | Pneumatic valve position control and actuator positioning |
| APPLICATION | Industrial process control, pneumatic control valves and valve actuator systems |
| MADE IN | China |
| REF NO | 189 |
