Detcon
The Detcon Standard Connector Board, Model Standard Connector Board, Part Number 500-005065-007, is a field wiring and interface PCB designed for Detcon Series 400 and Series 500 fixed gas detection systems. It provides power distribution, signal conditioning, and terminal connections between the gas sensor, transmitter electronics, and external control systems, ensuring reliable operation of combustible and toxic gas monitoring applications in industrial and marine environments.
BRAND
Detcon
TYPE
Standard Connector Board
PART NO.
500-005065-007
MODEL
Standard Connector Board
Full Technical Specifications ▶
| Parameter | Value / Description |
|---|---|
| BRAND | Detcon |
| TYPE | Standard Connector Board |
| PART NO. | 500-005065-007 |
| MODEL | Standard Connector Board |
| Voltage Rating | 24 VDC (Nominal input for Detcon Series 400/500 transmitters) |
| Application | Connector board for Detcon Series 400 & 500 fixed gas detectors including H₂S, CH₄, O₂, combustible and toxic gas transmitter assemblies. Provides field wiring termination, power input and sensor module interconnection. |
| Custom Bundle | No |
| Gas Compatibility | Hydrogen Sulfide (H₂S), Methane (CH₄) and other Detcon Series 400/500 gas sensors |
| Field Wiring | Screw Terminal Blocks |
| Connector Labels | MA, DC−, DC+, BLUE, YELL, BLACK, WHITE |
| PCB Material Rating | UL 94V-0 |
| Made In | USA |
| REF NO | 406 |
