Danfoss Solenoid Valve Coil BE230CS
The Danfoss BE230CS Solenoid Valve Coil (P/N: 018F6193) is an industrial electromagnetic coil designed to operate Danfoss solenoid valves in refrigeration, HVAC, and fluid control systems. It provides reliable actuation for precise control of liquid and gas flow, ensuring dependable performance in marine, industrial, and commercial automation applications.
BRAND
Danfoss
TYPE
Solenoid Valve Coil
PART NO.
018F6193
MODEL
BE230CS
Full Technical Specifications ▶
| Parameter | Value / Description |
|---|---|
| BRAND | Danfoss |
| TYPE | Solenoid Valve Coil |
| PART NO. | 018F6193 |
| MODEL | BE230CS |
| Supply Voltage | 220–230 VAC |
| Electrical Connection | DIN Spade Connector (3 Spade Terminals) |
| Actuator Size | 13.5 mm |
| Ambient Temperature | -40°C to +50°C |
| Insulation Class | Class H (IEC 85) |
| Connector Standard | EN 175301-803 |
| Application | Coil for Danfoss solenoid valves used in refrigeration, HVAC, industrial cooling systems, air conditioning equipment, and fluid control applications. Compatible with selected Danfoss EV210B, EV212B, EV220B, EV222B, EV224B, EV227B, EV250B and EV251B valve |
| Made In | Denmark |
| REF NO | 1514 |
