Danfoss Pressure Control Switch 061B100468
The Danfoss MBC 6100 (061B100468) is a heavy-duty industrial and marine pressure control switch designed for accurate pressure monitoring and control in harsh operating environments. It features a compact, rugged design with high vibration resistance, excellent repeatability, and marine approvals, making it ideal for pumps, compressors, hydraulic systems, lubrication circuits, filters, gearboxes, and other critical marine and industrial applications.
BRAND
Danfoss
TYPE
Pressure Control Switch (Heavy-Duty Marine Pressure Switch)
PART NO.
061B100468
MODEL
MBC 6100 (Specification Key: 2431-1DB04)
Full Technical Specifications ▶
| Parameter | Value / Description |
|---|---|
| BRAND | Danfoss |
| TYPE | Pressure Control Switch (Heavy-Duty Marine Pressure Switch) |
| PART NO. | 061B100468 |
| MODEL | MBC 6100 (Specification Key: 2431-1DB04) |
| Specification Key | 2431-1DB04 |
| Pressure Setting Range | 1–10 bar |
| Pressure Range (Metric) | 0.1–1 MPa |
| Maximum Working Pressure (PB/MWP) | 150 bar |
| Pressure Connection | G 1/4 Female (ISO 228-1) |
| Contact Function | SPDT (Single Pole Double Throw) |
| Contact Rating (AC15) | 0.5 A @ 250 VAC |
| Contact Rating (DC13) | 12 W @ 125 VDC |
| Electrical Connection | DIN 43650-A Connector (Industrial Plug) |
| Enclosure Protection | IP65 |
| Housing Material | Anodized Aluminium Alloy |
| Wetted Parts | Stainless Steel / FKM Diaphragm |
| Application | Pressure monitoring, alarm, shutdown and control for hydraulic systems, compressors, pumps, engines, marine machinery, filters and industrial automation |
| IEC | IEC / EN 60947-5 Compliant Industrial Pressure Control |
| Operating Pressure (Pe) | 0.1–1 MPa (1–10 bar) |
| Made In | Poland |
| REF NO. | 1371 |
