Danfoss MBS 33M Pressure Transmitter
Danfoss MBS 33M Pressure Transmitter (Part No. 060G3124) is a durable industrial pressure transmitter designed for accurate and reliable pressure measurement in hydraulic, pneumatic, marine, and industrial automation systems. It provides excellent long-term stability, fast response, and dependable performance in harsh operating environments, making it ideal for process control and machinery monitoring applications.
BRAND
Danfoss
TYPE
Pressure Transmitter
PART NO.
060G3124
MODEL
MBS 33M
Full Technical Specifications ▶
| Parameter | Value / Description |
|---|---|
| BRAND | Danfoss |
| TYPE | Pressure Transmitter |
| PART NO. | 060G3124 |
| MODEL | MBS 33M |
| MANUFACTURER | Danfoss |
| Pressure Range | 0 to 4 bar (0 to 400 kPa) Relative/Gauge Pressure |
| Permissible Overpressure (PB/MWP) | 8 bar (800 kPa) Maximum Working Pressure |
| Output Signal | 4–20 mA Analog Current Loop |
| Supply Voltage | 10–30 V DC (Max. 32 V DC) |
| Voltage Rating | 10–32 V DC |
| Electrical Connection | Angular Connector |
| Electrical Connection Size | M20 |
| Electrical Connection Standard | EN 175301-803-A |
| Pin Configuration | Pin 1: +Supply, Pin 2: –Common |
| Pressure Connection Type | G |
| Pressure Connection Size | 1/2" |
| Pressure Connection Standard | EN 837 |
| Enclosure Rating | IP65 |
| Approvals | CE, cULus UL Recognized |
| EU RoHS Compliance | Yes (with exemptions) |
| Application | Pressure measurement and monitoring in marine, hydraulic, refrigeration, industrial automation, and process control systems |
| IEC | EN 837 |
| Made In | Denmark |
| REF NO | 1386 |
