Danfoss A/S Frequency Inverter VLT® AutomationDrive FC-302
Danfoss 131B0494 is a variable frequency drive (VFD) designed to provide efficient speed and torque control of AC motors in industrial automation systems. It delivers energy-efficient motor operation, smooth acceleration and deceleration, integrated motor protection, and reliable process control, making it suitable for pumps, fans, conveyors, compressors, mixers, and a wide range of industrial machinery.
BRAND
Danfoss
TYPE
Frequency Inverter
PART NO.
131B0494
MODEL
VLT® AutomationDrive FC-302
Full Technical Specifications ▶
| Parameter | Value / Description |
|---|---|
| BRAND | Danfoss |
| TYPE | Frequency Inverter |
| PART NO. | 131B0494 |
| MODEL | VLT® AutomationDrive FC-302 |
| SERIES | FC-302 |
| Power Rating | 4.0 kW (400 V) / 5.0 HP (460 V) |
| Input Voltage | 3 × 380–500 V AC |
| Input Current | 9.0 / 7.4 A |
| Output Voltage | 3 × 0 V to Input Voltage |
| Output Frequency | 0–1000 Hz |
| Enclosure Rating | IP20 / Chassis |
| Ambient Temperature | Up to 50°C (122°F) |
| Communication Interface | Integrated RS-485 (FC Protocol / Modbus RTU supported) |
| Protection Features | Overcurrent, Overvoltage, Undervoltage, Overtemperature, Motor Protection, Short Circuit Protection |
| Application | Variable-speed control of AC motors for pumps, fans, conveyors, compressors, mixers, marine machinery, HVAC systems and general industrial automation. The FC-302 is designed for demanding industrial and marine applications requiring precise motor control |
| Made In | Denmark |
| REF NO | 500 |
