Bosch Rexroth SN1 Series Magnetic Proximity Sensor
The Rexroth / Aventics SN1-PN-K05U-030 (Part Number: 0830100613) is a high-precision magnetic piston position sensor manufactured by Bosch Rexroth AG / Aventics in Germany. Engineered for non-contact position tracking of magnetic pistons inside pneumatic cylinders, this Reed switch module operates within a voltage range of 10 to 30 V DC.
BRAND
REXROTH
TYPE
Piston Position Sensor
PART NO.
0830100613
MODEL
SN1-PN-K05U-030
Full Technical Specifications ▶
| Parameter | Value / Description |
|---|---|
| BRAND | REXROTH |
| TYPE | Piston Position Sensor |
| PART NO. | 0830100613 |
| MODEL | SN1-PN-K05U-030 |
| Voltage Rating | 10 ... 30 V DC |
| Application | Non-contact position tracking of magnetic pistons inside pneumatic cylinders |
| IEC | IP67 protection class rated enclosure conforming to IEC 60529 |
| Switching Element | Magnetic Reed Switch configuration with built-in protection resistor |
| Switching Point Accuracy | Exceptionally precise, maintaining tight limits within ±0.1 mm |
| Maximum Switching Frequency | Up to 2.0 kHz active polling frequency capabilities |
| Shock Resistance Limit | Rated to handle extreme mechanical impulses up to 50 g / 11 ms |
| Vibration Durability | Built to withstand continuous structural frequencies up to 30 g |
| Status Visualizations | Integrated high-visibility yellow operating status LED |
| Housing Construction | Lightweight, chemically shielded Polyamide (PA) composite shell |
| Cable Connection Layout | Pre-wired heavy-duty PVC jacketed pigtail drop assembly line |
| Thermal Operating Window | -10°C to +70°C |
| Made In | Germany |
| REF NO | 168 |
